Home > products > Magnetic Particle Testing > Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234
Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234
Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234
Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234
Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234

Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234

Product Details

Place of Origin: Beijing

Brand Name: HUATEC

Certification: ISO, CE, GOST

Model Number: 3C2-234

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Packaging Details: Standard export package

Delivery Time: 1-4days

Payment Terms: T/T, Paypal, Western Union

Supply Ability: 500pcs per month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

asme magnetic flux indicator

,

quantitative quality magnetic flux indicator

,

qqi magnetic flux indicator

Material:
DT4A Electromagnetic Pure Iron Plate
Color:
Metal Surface Presents Bright Silver, No Rust.no Scratch, No Corrosion And So On
Planeness:
Put The Test Piece On Bare Board, Parallel Completely.no Wrinkle.no Burts.the Surface’s Roughness RA Is 0.005inch
Flaw Depth:
Variable Depth Flaws Of 20%, 30% And 40% Of Shim Thickness
Thickness Of Test Piece Cx4-230:
0.002inch
Product Name:
NDT QQI Test Shim
Material:
DT4A Electromagnetic Pure Iron Plate
Color:
Metal Surface Presents Bright Silver, No Rust.no Scratch, No Corrosion And So On
Planeness:
Put The Test Piece On Bare Board, Parallel Completely.no Wrinkle.no Burts.the Surface’s Roughness RA Is 0.005inch
Flaw Depth:
Variable Depth Flaws Of 20%, 30% And 40% Of Shim Thickness
Thickness Of Test Piece Cx4-230:
0.002inch
Product Name:
NDT QQI Test Shim
Product Description

ASME ASTM Standard Quantitative Quality Indicators Magnetic Flux Indicator QQI Test Shim 3C2-234



Overview

HUATEC Group Quantitative Quality Indicators are magnetic particle test shim with artificial defects used to verify proper field direction and adequate field strength. NDT QQI shims are a valuable tool to be used to establish testing criteria with Multi-Directional 2-D and 3-D type testers and to increase productivity by minimizing magnetizing shots.

NDT QQI shims are both thin and flexible to conform to the geometry of the test shim. They must be held in intimate contact with the test piece by either tape or glue.



Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234 0



Specifications

Inspection items The condition, method and demand of the test Inspection demand
Color Metal surface presents bright silver, no rust.no scratch, no corrosion and so on Passed muster
Planeness Put the test piece on bare board, parallel completely.no wrinkle.no burts.the surface’s roughness RA is 0.8um Passed muster
The size of sheet iron and cutting groove

The side length of test piece tested by milscale is 0.75in×0.75in.the average thickness of test piece 2-234 is 0.002in .The artificial defect three“o”tested by precision microscope are all on the center of the test piece.The diameter of big “o”is 0.507 in,middle “o”is 0.383in ,small“o”is 0.258in,

Test piece 2-234,big“o”, thickness:0.002in ,groove depth:0.0004in,groove width:0.007in,middle“o” ,thickness:0.002in,groovc depth:0.0006in,groove width:0.007in,small“o”,thickness:0.002in,groove depth:0.0008in,groove width:0.007in.

 Passed muster
Quality

The physics and chemistry test show the result that the metal is made from DT4A electromagnetic pure iron plate.

The analytic result of raw materials accords with the rule of GB6985,

 Passed muster




Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234 1

Other Magnetic flaw  detectors test block:



MT  test block

Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234 2

Type N1: 45N, 5kgs

Type N2: 118N 12kgs

Type N3: 177N 18kgs



MT standard block

Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234 3

Katos rong type B: DC HRC=90～95, 12 drilling through holes diameter  0.07inch, center hole diameter 31.8mm





Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234 4

Type E: AC



Asme Quantitative Quality Magnetic Flux Indicator Qqi Test Shim 3c2-234 5

 MTU test blcok

Tags:

magnetic flaw detector,

mt test specimen,

asme magnetic flux indicator
