Real-Time Spectral Chart Vibration Meter Vibration Analysis Meter Handheld Vibration Analyzer

Product Details

Place of Origin: Beijing

Brand Name: HUATEC

Certification: ISO, CE, GOST

Model Number: HG6380

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Packaging Details: Standard export package

Delivery Time: 1-4days

Payment Terms: T/T, Paypal, Western Union

Supply Ability: 500pcs per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                portable vibration meter, vibration analyzer


Transducer:	Piezoelectric Acceleration Transducer	Parameters:	RMS Of Velocity Values, Peak-peak Value Of Displacement, Peak Values Of Acceleration Or Real-time Spectral Charts
Speed Testing:	Rotational Speed	Standards:	GB 13823.3
Display:	TFT 320×200 Pixels With RGB	Printer:	Integrated Thermal
Battery:	Rechargeable Li Battery,1500mAh	Main Unit Weight:	320g

Transducer:	Piezoelectric Acceleration Transducer
Parameters:	RMS Of Velocity Values, Peak-peak Value Of Displacement, Peak Values Of Acceleration Or Real-time Spectral Charts
Speed Testing:	Rotational Speed
Standards:	GB 13823.3
Display:	TFT 320×200 Pixels With RGB
Printer:	Integrated Thermal
Battery:	Rechargeable Li Battery,1500mAh
Main Unit Weight:	320g

Product Description

Real-Time Spectral Chart Vibration Meter Vibration Analysis Meter Handheld Vibration Analyzer

HG-6380 uses piezoelectric acceleration transducer to convert vibration signal into electric signal. Results including RMS of velocity values, peak-peak value of displacement, peak values of acceleration or real-time spectral charts are displayed or printed out. It can not only measure the three parameters, but also rotational speed.

The vibration meter is designed to test conventional vibration, especially the vibration test in rotating and reciprocating machines. It can test the acceleration, velocity, and displacement of vibration as well as rev (or inherent frequency), also perform simple failure diagnosis.

The technical specifications of HG-6380 comply with the requirements of GB 13823.3. HG-6380 is widely used in machinery, power, metallurgy, automobile and other industrial fields.

Specifications:

Model name	HG-6380
Testing range (Metric)	Acce: 0.1 ~ 205.6 m/s²(peak) Velo: 0.1 ~ 400.0 mm/s(RMS) Disp: 0.001 ~ 9.0 mm(peak-peak)
Testing range (Imperial)	Acce: 0.01 ~ 22.00 g(peak) Velo: 0.01 ~ 15.75 in/s(RMS) Disp: 0.1 ~ 356.3 mil(peak-peak)
Freq range	Acceleration: 10Hz ~ 200Hz, 10Hz ~ 500Hz,10Hz ~ 1KHz, 10Hz ~ 10KHz Velocity: 10Hz ~ 1KHz Displacement: 10Hz ~ 500Hz
Frequency resolution	0.25Hz
Data memory	100 × 80 pieces of data and 100 spectrums
Software	Yes
Temp	0℃ ~ 40℃
Tolerance	±5%
Speed measuring range	30 ~ 300000 rpm corresponding to 0.5 ~ 5000Hz
Measuring distance	0.15 ~ 1m
Display	TFT 320×200 pixels with RGB
Data interface	USB
Overall dimensions	212×80×35
Printer	Integrated thermal
Weight	320g
Battery	Rechargeable Li battery,1500mAh
Continuous working time	About 50h

PC software sample

Standard delivery

Main unit. 1pc

Power Adapters

(input:220V/50Hz, output:9V/1000mA) 1pc

Power Adapters (input:110V/50Hz,output:9V/1000mA) 1pc

Piezoelectric sensors 1pc

Magnetic seat (with 2 bolts) 1pc

Manual 1pc

Package case 1pc

Optional accessories

Speed transducer (Lacer)

PC Software

Communication cable 1pc

Probe
