DAC AVG DGS Curves Portable Usm Go Ultrasonic Flaw Detector

Digital Portable DAC, AVG DGS Curves USM Ultrasonic Flaw Detector GO Portable Flaw Detector

This is a portable industrial non-destructive flaw detector, which can rapidly, easily and accurately inspect, locate, evaluate and diagnose various defects (crack, inclusion and pinhole, etc.) in a work-piece without destruction. It can be used both in a lab and field. The instrument can be widely used in any fields that need defect inspection and quality controlling e.g. manufacturing industry, iron & steel metallurgical industry, metalworking, chemical industry, etc., also be broadly used in the active safety inspection and service-life evaluation in such fields as aerospace, railway transportation and boiler pressure vessels, etc. It is an essential instrument for non-destructive inspection industry.

When the ultrasonic wave propagates in a job, one can detect the defect in it by the influence on the propagation of ultrasonic wave based on the acoustic characteristic demonstrated by the defect in the material. Based on this principle, by using ultrasonic wave one can measure such defects as crack, pinhole and inclusion in such media as metal, non metal and composite, etc.

Performance Features

• The dual CPUs work in coordination, high speed detecting and data processing；
• Automatic calibration；
• Easy tests of thickness and sound velocity of materials;
• Freely set standards for various industries to meet different flaw detection
• Automated display precise flaw location(Depth d,level p,distance s,amplitude,dB,diameter ф)；
• Freely set standards for various industries to meet different flaw detection；
• The echo suppression is adjustable from 0 to 90%, without affecting the dB gain and linearity；
• DAG and AVG(DGS) curves are generated automatically;
• Muti-functions for easy detection: peak memory, Display freeze, automatic gain & wave search；
• Li -battery, continue working time up to 10 hours;
• Storage: 500 sets of flaw detection process and data storage;
• Provides high contrast viewing of the waveform from bright, direct sunlight to complete darkness and easy to read from all angles;
• USB connects to computer,automatically generate flaw detection report;

Technical Parameters

Standard delivery

Optional Accessories

Straight probe (5MHZ-ф20)
Straight probe (2.5MHZ-ф20)
Straight probe (2.25MHZ-ф20)
Straight probe (1MHZ-ф20)
Angle probe (4MHZ-45degree, 8*9mm)
Angle probe (4MHZ-60degree, 8*9mm)
Angle probe (4MHZ-70degree, 8*9mm)
Angle probe (4MHZ-80degree, 8*9mm)
Angle probe (2MHZ-45degree, 8*9mm)
Angle probe (2MHZ-60degree, 8*9mm)
Angle probe (2MHZ-70degree, 8*9mm)
Angle probe (2MHZ-80degree, 8*9mm)
Probe T/R (5MHz-ф20mm, focus 15mm)
Probe T/R (2.5MHz-ф20mm, focus 15mm)
Connection cable to probe (BNC-BNC)
Connection cable to probe (BNC-Lemo 00)
Connection cable to probe (Lemo 01-BNC)
Connection cable to probe (Lemo 01-Lemo 00)
Lithium ion battery
Power adapter (4A/9V)
Power Cable
Leather case
Test block V1
Test block V2
Test blocks DAC, ASME etc.
