Metal And Non Metal Automatic Digital Hardness Testers Built In Printer

  • Metal And Non Metal Automatic Digital Hardness Testers Built In Printer
  • Metal And Non Metal Automatic Digital Hardness Testers Built In Printer
Place of Origin Beijing
Brand Name HUATEC
Certification ISO, CE, GOST
Model Number HB-3000MF
Minimum Order Quantity 1pcs
Packaging Details Standard export package
Delivery Time 1-4days
Payment Terms T/T, Paypal, Western Union
Supply Ability 500pcs per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Digital Screen Touch Screen Advanced Technology Auto Turret, Specimen Atuto Raise, Indentation Auto Press
Image Of Indentation Will Be Focused Automatically Brinell Scale HBW2.5/62.5 HBW2.5/187.5 HBW5/125 HBW5/750 HBW10/100、
Max Height Of Specimen 200mm (Added Height Type: 400mm For Specially Making) Carried Standard GB/T231.2 Chinese Standard, JJG150 Inspection Rule
Readout Hardness Value LCD Screen Displays, Print Output, Built-in Printer
Highlight

vickers hardness machine

,

portable brinell hardness tester
Leave a Message
Product Description



Metal And Non Metal Automatic Digital Hardness Testers Built In Printer



Main Functions Introduction:



This model semi-automatic Brinell hardness tester made according to Chinese standard <<GB/T231.1 (ISO6506-1) Metal Brinell Hardness Test>> is used to test the Brinell hardness value of metals and some non-metals materials.

This hardness testers with high accuracy and automation fits for high-end clients with larger workload test or high precision requirements



● Specimen will be raised up automatically

● Automatically load the test force

● Automatically press the indentation

● Specimen will be lowered down automatically

● Turret turns automatically.

● The image of indentation will be focused automatically

● The hardness value will be digitally displayed



Main Technical Specifications:

Brinell Scale

HBW2.5/62.5  HBW2.5/187.5  HBW5/125    HBW5/750    HBW10/100,

HBW10/1500  HBW10/3000   HBW10/250   HBW10/500   HBW10/1000

Test Force

62.5kgf(612.9N),100kgf(980.7N),125kgf(1226N),187.5kgf(1839N),250kgf(2452N), 500kgf(4903N),750kgf(7355N),1000kgf(8907N),1500kgf(14710N),3000kgf(29420N)

Max Height of Specimen

200mm (Added height type: 400mm for specially making)

Min Test Unit

0.625um

Weight of Instrument

About 90 Kg

Power Supply

AC220+5%,50~60Hz

Overall Dimension

550x210x750mm

Dwelling Time

5~60s

Hardness test Range

8~650HBW

Total Magnification of Microscope

20X

Carried Standard

GB/T231.2 Chinese Standard, JJG150 Inspection Rule

Distance between Indenter to outer wall

135mm

Readout Hardness Value

LCD Screen Displays, Print Output, Built-in Printer

Rise Up Specimen

Automatically / Manually

Press Indentation

Automatically

Turn Turret

Automatically / Manually

Move Down Specimen

Automatically / Manually

Hardness Tested Value

Digitally display and print
