Home > products > Shore Durometer > Digital ASTMD2240 / JISK7215 0 - 100HC Shore Durometer HT-6510C

Digital ASTMD2240 / JISK7215 0 - 100HC Shore Durometer HT-6510C

Product Details

Place of Origin: Beijing

Brand Name: HUATEC

Certification: ISO, CE, GOST

Model Number: HT-6510C

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Packaging Details: Standard export package

Delivery Time: 1-4days

Payment Terms: T/T, Paypal, Western Union

Supply Ability: 500pcs per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                digital shore durometer, portable shore durometer


Measurement Range:	0-100HC	Measurement Deviation:	＜1%H
Power Supply:	4x1.5V AAA (UM-4) Battery	Battery Indicator:	Low Battery Indicator

Measurement Range:	0-100HC
Measurement Deviation:	＜1%H
Power Supply:	4x1.5V AAA (UM-4) Battery
Battery Indicator:	Low Battery Indicator

Product Description

Digital Shore Durometer Form Hardness Tester Plastic Durometer

Product synopsis

Product info: digital durometer for shore hardness testing pocket size model with integrated probe

Test scale: shore hardness

Standards: DIN53505, ASTMD2240, ISO7619, JISK7215

Parameters displayed: hardness result, average value, max. value

Measurement range:0-100HC

Measurement deviation:＜1%H

Resolution: 0.1

Auto switch off

With RS232C interface

Operating conditions: 0℃ to 40℃

Power supply: 4x1.5V AAA (UM-4) battery

Battery indicator: low battery indicator

Dimensions: 162x65x38mm

Weight (not including probe):173g

Standard accessories:
Main unit
Zero Calibration plate
Carrying case
Instruction Manual
Certificate

CALIBRATION CHECK
To check whether the tester is accurate, just Insert the indenter into the hole of the calibrated test Block. Apply enough force to make firm contact between the top surface of the test block and the presser foot. The reading
should agree with the value stamped on the test block. If not, just carry out Zero calibration and High end calibration.

Zero calibration
Hold the durometer vertically with the point of the indenter hanging in the air, the reading on the display should be '0'. If not, depress the 'ZERO' key to make the tester display '0' .

High end calibration
Just place the indenter onto a flat glass, apply enough force to make firm contact between the glass and the presser foot. The readings on the display should lie between 99.5 and 101. If not, press CAL key to carry out high end calibration.

BATTERY REPLACEMENT
When the battery symbol appears on the display, it is time to replace the batteries.
Slide the Battery Cover away from the tester and remove the batteries.
Install batteries paying careful attention to polarity.

NOTE
Readings below 10HD for Shore D type may be inexact and should not be reported for some materials. Measurements should be made on a Shore A type.
Readings above 90HA for Shore A should be made on a Shore D type durometer
